Fuse-Link
5 x 20 / 6.3 x 32 mm
Rated Voltage
500 VAC (VDE), 600 VAC/DC (UL/CSA)
Rated current
10 A (VDE), 20 A (UL/CSA)
Rated Power Acceptance IEC
4 W / 10 A for 6.3x32 mm fuse-link
3.2 W / 10 A for 5x20 mm fuse-link
Degree of Protection
IP40
Admissible Ambient Temp.
-40 °C to 85 °C
Material: Cap
fingergrip: Thermoset, UL 94V-0
slotted: Thermoplastic
Storage Conditions
0 °C to 60 °C, max. 70% r.h.
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about Approvals
SCHURTER products are designed for use in industrial environments. They have approvals from independent testing bodies according to national and international standards. Products with specific characteristics and requirements such as required in the automotive sector according to IATF 16949, medical technology according to ISO 13485 or in the aerospace industry can be offered exclusively with customer-specific, individual agreements by SCHURTER.
Product standards that are referenced
Organization | Design | Standard | Description |
---|---|---|---|
Designed according to | IEC 60127-6 | Miniature fuses. Part 6. Fuse-holders for miniature fuse-links | |
Designed according to | UL 4248-1 | Industrial Control Equipment | |
Designed according to | CSA C22.2 no. 4248.1 | Industrial Control Equipment |
Application standards where the product can be used
Organization | Design | Standard | Description |
---|---|---|---|
Suitable for applications acc. | IEC/UL 62368-1 | Audio/video, information and communication technology equipment - Part 1: Safety requirements |
The product complies with following Guide Lines
Identification | Details | Initiator | Description |
---|---|---|---|
SCHURTER AG | Directive RoHS 2011/65/EU, Amendment (EU) 2015/863 | ||
SCHURTER AG | The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March 2007. It is similar to the EU directive RoHS. | ||
SCHURTER AG | On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration, Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as "REACH") entered into force. |
Cap | Fuse-Link (mm) | Color |
Order Number
|
Free Sample Free Sample
|
Distributor Stock Check Distributor Stock Check
|
... |
---|---|---|---|---|---|---|
slotted | 5 x 20 | black | 0031.1611 | ... | ||
slotted | 6.3 x 32 | black | 0031.1613 | ... | ||
Fingergrip | 6.3 x 32 | black | 0031.1616 | ... |
Packaging Unit | Plastic Bag (100 pcs.) |
